15 psi design pressure 14-gauge, fully-welded, 304 stainless steel exterior shell with #4 brush 11-gauge, 304 stainless steel interior shell Interior finished to Ra 0.8 micron sanitary finish and passivated 60-degree cone bottom, jacketed Independent dimpled cooling jackets (cone and cylinder) with individual glycol inlet and outlet Rotating rack arm with butterfly valve and cover Bottom dump 1.5″ tri-clamp fitting with butterfly valve, elbow, and cover Sample valve CIP arm with spray ball and piping Blow-off port Vacuum and pressure relief valve 4″-thick polyurethane insulation for cooling jacket and cone Shadowless side manway door 10″ diameter top hatch 3″ dial thermometer Pressure gauge

SPECIFICATIONS 7 BBL     Height 89.5″ Width 48″ Empty Weight 672lbs Gross Volume 273 Net Volume 250 % Head Space 20% Pressure Rating 15 psi Glycol Jacket Pressure Rate 3 bar = 43.5 psi Insulation Thickness 80mm Manway Location Front Leg Support Leveling Feet
