Key features include:
15 psi design pressure 14-gauge, fully-welded, 304 stainless steel exterior shell with #4 brush 11-gauge, 304 stainless steel interior shell Interior finished to Ra 0.8 micron sanitary finish and passivated 60-degree cone bottom, jacketed Rotating rack arm with butterfly valve and cover Bottom dump 1.5″ tri-clamp fitting with butterfly valve, elbow, and cover Sample valve CIP arm with spray ball and piping Blow-off port Vacuum and pressure relief valve 2″-thick polyurethane insulation for cooling jacket and cone Large 17″ diameter top hatch 3″ dial thermometer Pressure gauge
SPECIFICATIONS
3.5 BBL
Height
83″
Width
31.5″
Empty Weight
440lbs
Gross Volume
148
Net Volume
130
% Head Space
20%
Pressure Rating
15 psi
Glycol Jacket Pressure Rate
3 bar = 43.5 psi
Insulation Thickness
60mm
Manway Location
Top
Leg Support
Leveling Feet
